210 FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH
Specifications
Subject to change without notice
6.1 Technical Data
Version EX-S EX/EX-RE EX-PR
Measuring parameter
Measuring principle Ultrasonic transmit time measurement method
Measuring values
Mass flow, standard and actual volumetric flow, molecular weight, totalized standard volume and mass, gas
velocity, gas temperature, speed of sound
Measuring range
1)
Standard: 0.03 ... ± 120 m/s Standard: 0.03 ... ± 90 m/s
Accuracy
2) 3)
1-path measurement:
2-path measurement:
± 1.5
4)
... 5.0% / ± 0.5%
5)
of reading, at range 0.3m/s up to
± 1.0
4)
... 3.0% / ± 0.5%
5)
max. value of measuring range
Accuracy of molecular
weight
3)
< 2% of reading at range 2 ... 120 kg/kmol
Accuracy of mass flow
3)
1-path measurement: ± 2.5
4)
... 5.0% of reading, at range 0.3m/s up to
2-path measurement: ± 2.0
4)
... 4.0% max. value of measuring range
Resolution 0.001 m/s
Repeatability 0.2% at 10 m/s
Rangeability Max. 4000:1 Max. 3000:1
Internal pipe diameter
6)
4” to 24” 8” to 72”
7)
12” to 72”
Measurement conditions
Gas temperature
8)
● Standard range:
● High temperature range zone 1:
zone 2:
● Low temperature range
9)
:
-70 ... +180°C (-95 ... 356 °F)
-70 ... +280°C (-95 ... 535 °F)
-70 ... +260°C (-95 ... 500 °F)
-196 ... +100°C (-325 ... 210 °F)
Pressure range
- 0.5 ... 16 barg
0,5 barg for operating the retraction mechanism on retractable version FLOWSIC100 EX-PR
Ambient conditions
Temperature range
● Sender/receiver units
10)
: - 40 ... +70°C (- 40 ... 158 °F); option: - 50 ... +70°C (- 58 ... 158 °F)
● MCUP control unit
11)
: -40 ... +60°C (- 40 ... 140 °F) ;- 20 ... +50 °C (- 4 °F ... 122 °F) for 19” rack
Storage temperature
● Sender/receiver units:
● MCUP
11)
:
-40 ... +70°C (-40 ... 158 °F); option: -50 ... +70°C (-58 ... 158 °F)
-40 ... +70°C (-40 ... 158 °F)
Relative humidity <95% (Use suitable corrosion protection for carbon steel nozzles)
Ex approvals
Sender/receiver unit,
zone 1
● ATEX II 1/2 G Ex d [ia Ga] IIC T4
Ga/Gb
● ATEX II 1/2 G Ex d e [ia Ga] IIC
T4 Ga/Gb
● IECEx Ga/Gb Ex d [ia] IIC T4
● CSA Cl I, Div1 Group B, C, D
● CSA Cl I, Div2 Group A, B, C, D
● CSA Cl I, zone 1/zone 2 IIC T4
Optional:
● Temperature code T6
● Zone 0 for ultrasonic
transducers
● ATEX II 2 G Ex d IIC T4 Gb
● ATEX II 2 G Ex d e IIC T4 Gb
● IECEx Ex d IIC T4
● CSA Cl I, Div1 Group B, C, D
● CSA Cl I, Div2 Group A, B, C, D
● CSA Cl I, zone 1/zone 2 IIC T4
Optional:
● Temperature code T6
● ATEX II 1/2 G Ex d [ia Ga] IIC T4 Ga/Gb
● ATEX II 1/2 G Ex d e [ia Ga] IIC T4 Ga/
Gb
● IECEx Ga/Gb Ex d [ia] IIC T4
● CSA Cl I, Div1 Group B, C, D
● CSA Cl I, Div2 Group A, B, C, D
● CSA Cl I, zone 1/zone 2 IIC T4
Optional:
● Temperature code T6
● Zone 0 for ultrasonic transducers
Sender/receiver unit,
zone 2
● ATEX II 3 G Ex nA IIC T4 Gc
MCUP control unit, CSA CSA Cl I, Div 1, Groups A, B, C, D; T6; 4X/IP66, enclosure type 4
11)
CSA Cl I, Div 2, Groups A, B, C, D; T4; 4X/IP66, enclosure type 4
11)
MCUP control unit, zone 1 ATEX II 2 G Ex de IIC T6
MCUP control unit, zone 2 ATEX II 3 G Ex nA IIC T4 Gc
