238 FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH
Specifications
Subject to change without notice
6.3 Options for MCUP control unit
6.3.1 Inputs/outputs
6.3.2 Interface module
6.3.3 Interface modules for MCUP 19" version
6.4 Password
Designation Part No.
Analog input module, 2 channels, 100 Ω, 0/4...22 mA, electrically isolated 2034656
Analog output module, 2 channels, 500 Ω, 0/4 ... 22 mA,
electrically isolated per module
2034657
Digital output module, 2 changeover contacts 2034659
Module carrier (for one each AI, AO, DI or DO module) 6033578
Connection cable for optional I/O modules 2040977
I/O module carrier 19" (to install up to 4 AI/AO or 4 DI/DO modules) 2048378
Designation Part No.
Interface Modbus TCP + Impulse 2059546
Interface Ethernet triplex + Impulse 2072693
Interface Foundation Fieldbus on request
Interface Impulse 2048961
Interface Profibus DP + Impulse 2048920
Interface Ethernet + Impulse 2055719
Interface Modbus + Impulse 2048958
Interface HART® BUS + Impulse 2050607
Designation Part No.
Interface Modbus TCP + Impulse on request
Interface Ethernet triplex + Impulse 2073110
Interface Impulse 2049348
Interface Profibus DP + Impulse 2049334
Interface Ethernet + Impulse 2048377
Interface Modbus + Impulse (on request) 2050674
Interface HART® BUS + Impulse (on request) 2050608
User level Password
0 "Operator" Without
1 "Authorized client" sickoptic
