Product Description
FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH 29
Subject to change without notice
2.1.4 System overview
The measuring system consists of the following components:
FLSE100 sender/receiver unit (details
pg. 31, § 2.2.1)
For sending and receiving ultrasonic pulses, for signal processing and control of system
functions
Nozzle (details
pg. 55, § 2.2.2.1)
For mounting the sender/receiver units on the pipeline
Nozzle installation tool
For precise positioning and alignment of nozzles
Ball valve (details
pg. 57, § 2.2.2.2)
For mounting retractable sender/receiver units on the pipeline
MCUP control unit (details
pg. 59, § 2.2.4)
For control, evaluation and output of the sensor data connected via the RS485
interface
Connection cable between the sender/receiver units
Connection cable between sender/receiver units and MCUP
Meter body option (spool piece)
Spool piece ready for mounting in an existing pipeline (flange connection or welded
connection); including installation materials to fit the sender/receiver units.
External temperature and pressure transmitters available on request
Component
Device type
FLOWSIC100 EX-S FLOWSIC100 EX FLOWSIC100 EX-RE FLOWSIC100 EX-PR
Sender/receiver unit
FLSE100-EXS (master) FLSE100-EX (master) FLSE100-EXRE (master) FLSE100-EXPR
FLSE100-EXS (slave) FLSE100-EX (slave) FLSE100-EXRE (slave)
Installation
material
non-retractable
FLSE100
ANSI CL150 2" or DN50 PN16 nozzle ANSI CL150 3" or
DN80 PN16 nozzle
retractable
FLSE100
Nozzle, ball valve, blind flange ANSI CL150 2"/CL150 3"or DN50 PN16/DN80 PN16
MCUP
without explosion
protection
MCUP 90-250 V a.c. or 24 V d.c.
explosion-
protected
FLSE100 certified for Ex zone 1:
MCUP Zone 1 (90 ... 250 V a.c. or 24 V d.c.)
MCUP Zone 2 (24 V d.c., 115/230 V a.c.automatically
controlled)
FLSE100 with suitability for Ex zone 2:
MCUP Zone 2 (24 V d.c. or 115/230 V a.c. automatically
controlled )
Connection cable FLSE100
(master )-FLSE100 (slave)
Scope of delivery Not relevant
Measuring systems with meter body option can be provided additionally as:
Dry calibrated (3D measured measurement system. Geometric uncertain-
ties are minimized.)
Flow calibrated (Complete measurement system calibrated on a flow test
bench.)
Both variants reduce the measurement uncertainty (
pg. 210, § 6.1).
