Product Description
FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH 57
Subject to change without notice
2.2.2.2 Ball valve
Ball valves are only required for retractable sender/receiver units.
Ball valve according to ANSI
Ball valve according to DIN
Component Connection Material (ASTM)
Gas temperature
range
Max. pressure VL [mm] Use for
Standard Temperature
Ball valve
CL150 2" SS
CL150 2" Stainless steel
1.4408 (CF08M)
-100 … +200 °C 16 bar
@ -10 ... +150 °C
178 FLSE100-EXS, EXRE
Ball valve
CL150 3" SS
CL150 3" 203 FLSE100-EXPR
High Temperature
Ball valve
CL150 2" SS
CL150 2" Stainless steel
1.4408 (CF08M)
-50 … +350 °C 16 bar
@ -10 … +150 °C
178 FLSE100-EXS, EXRE
Ball valve
CL150 3" SS
CL150 3" 203 FLSE100-EXPR
Low temperature
Ball valve
CL150 2" SS
CL150 2" Stainless steel A182
F316 Ti / A351
(CF08M)
-196 … +100 °C 16 bar
@ -196 … +20 °C
178 FLSE100-EXS, EXRE
Ball valve
CL150 3" SS
CL150 3" 203 FLSE100-EXPR
Component Connection Material (ASTM)
Gas temperature
range
Max. pressure VL [mm] Use for
Standard Temperature
1
1
High and low temperature ball valves acc. to DIN on request.
Ball valve
PN16 DN50
SS
PN16 DN50 Stainless steel
1.4408
-50 … +200 °C 16 bar
@ -10 ... +150 °C
(acc. EN 1092-1,
table 4.4.1-4)
150 FLSE100-EXS, EXRE
Ball valve
PN16 DN80
SS
PN16 DN80 180 FLSE100-EXPR
