Product Description
Subject to change without notice
Nozzle, blind flange and seal according to DIN
1)
: Take into account additional 3 mm ”welding space” for nozzles of type "Long Welding Neck"
2)
: Nozzle length 235 mm for pipe size 12”
3)
: Other sealing material on request
4)
: According to diagrams of pressure/temperature ranges (e.g. → pg. 41, Fig. 7)
Component Connection Material max. pressure
4)
L [mm]
1)
Use for
Nozzle
Nozzle PN16 DN50 CS 90° PN16 DN50 Carbon steel
P350GH
16 bar @
-10 ... +100 °C
161,5 FLSE100-EXS
Nozzle PN16 DN50 CS 75° 209,0 FLSE100-EX/EXRE
Nozzle PN16 DN80 CS 75° PN16 DN80 A105 (ASTM) 205,0
2)
FLSE100-EXPR
Blind flange
Blind flange PN16 DN50 CS PN16 DN50 Carbon steel
P350GH
16 bar @
-10 ... +100 °C
- FLSE100-EXS, EXRE/EX
Blind flange PN16 DN80 CS PN16 DN80 FLSE100-EXPR
Seal 2"
Seal B9A PN16 DN50
1.4571
3)
PN16 DN50 Stainless steel 316
L or 316 Ti, graphite
16 bar absolute @
-196 ... +280 °C
-
FLSE100-EXS, EX, EXRE
Seal 3"
Seal B9A PN16 DN80
1.4571
3)
PN16 DN80 Stainless steel 316
L or 316 Ti, graphite
16 bar absolute @
-196 ... +280 °C
-
FLSE100-EXPR
