SICK FLOWSIC100 Flare User Manual

Specifications
FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH 233
Subject to change without notice
6.2.8 Additional accessories for retractable sender/receiver units
6.2.9 MCUP control unit
MCUP without explosion protection
Fig. 163 MCUP control unit without explosion protection in compact size housing
Designation Part No.
Blind flange 2" for FLSE100-EXS and FLSE100-EXRE
Blind flange ANSI CL1502Z CS, material carbon steel 2051991
Blind flange 3" for FLSE100-EXPR
Blind flange ANSI CL1503Z CS, material carbon steel 2051990
Ball valve 2" for FLSE100-EXS and FLSE100-EXRE
Ball valve ANSI CL1502Z SS, material stainless steel 1.4408 (CF08M) 2051963
Ball valve 3" for FLSE100-EXPR
Ball valve ANSI CL1503Z SS, material stainless steel 1.4408 (CF08M) 2051966
300
210
160
320
340
125
Designation Part No.
Control unit MCUP-WNA1MN00000NRN 1050334
Control unit MCUP-2NA1MN00000NRN 1047618
