Product Description
FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH 59
Subject to change without notice
2.2.4 MCUP control unit
The control unit has the following functions:
Control of the data transfer and processing of the sender/receiver unit data connected
via the RS485 interface.
Signal output via analog output (measured value) and relay outputs (device status)
Signal input via analog and digital inputs
Voltage supply of the connected sender/receiver units
Communication with higher level control systems via optional modules
Plant and device parameters can be set easily using a laptop and user friendly operating
program via:
Service interface USB 1.1 or RS232
Service interface RS485 (standard for ex-protected MCUP)
The parameters are stored reliably even in case of power failure.
