Product Description
Subject to change without notice
Versions
1): not applicable for USA and Canada
Version Explosion protec-
tion / applied
standards
Housing type Power supply Cable entries Options
MCUP non-
Ex
- Wall housing,
compact size,
painted steel
24 V d.c.
90 ... 250 V
a.c.
4 x M20, 1x M16
(cable glands
included);
1 x M25 (plug)
-
Wall housing,
Medium size,
painted steel
9x M20, 5x M25
(3 measuring
points)
NPT cable entries
and flange plate
connection, cable
glands, painted
stainless steel
housing
19” rack, alumin-
ium
Terminals -
MCUP
ATEX
1)
II 3 G Ex nA IIC T4
Gc
Wall housing,
Medium size,
painted steel
24 V d.c. 115/
230 V a.c.
automatically
controlled
9 x M20, 5 x M25 (3
measuring points)
NPT cable entries
and flange plate
connection, cable
glands, painted
stainless steel
housing
II 2 G Ex de IIC T6 Wall housing Ex-d
with Ex-e terminal
compartment,
size 4 (type
STAHL), painted
aluminum
24 V d.c. 90 …
250 V a.c.
9 x M20, 5 x M25 (1
or 2 measuring
points), flange plate
connection
NPT cable entries,
3 measuring
points, cable
glands, painted
stainless steel
housing
Wall housing Ex-d
with Ex-e terminal
compartment,
size 6 (type
STAHL), alumi
-
num
MCUP CSA CSA Cl I, Div 1 Wall housing Exd,
size 4 (type
STAHL), painted
aluminum
100 … 240 V
a.c.
24 V d.c.
3x3/4" NPT, 6x1/2"
NPT
Cable glands
Wall housing Exd,
size 6 (type
STAHL), painted
aluminum
5x3/4" NPT, 9x1/2"
NPT
CSA Cl I, Div 2; Cl
I, zone 2
Wall housing,
Medium size,
painted steel
24 V d.c. 115/
230 V a.c.
automatically
controlled
9 x 1/2" NPT, 5 x 3/
4" NPT (3 measur
-
ing points), flange
plate connection
Painted stainless
steel housing,
cable glands
