1.5 Transport safety device for retractable sender/receiver units
To prevent transport damage, retractable sender/receiver units must be secured before
each transport according to
Fig. 1:
The transducer must be on the retraction flange.
The probe tube with transducer must be secured with cotter pins.
Fig. 1 Transport safety device for retractable sender/receiver unit (shown semitransparent)
Retraction flange
Transducer
Probe tube
Cotter pin
