Specifications
FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH 235
Subject to change without notice
MCUP without explosion protection and for use in zone 2 and CL I, Div 2
Fig. 165 MCUP control unit in medium size housing
POWER
Meas
H
330
356
242 29
∅ 10
Designation Part No.
Control unit MCUP-WNB3MN00000NRN 1050336
Control unit MCUP-2NB3MN00000NRN 1050335
Control unit MCUP-SNB3MB00000NSN 1050337
Control unit MCUP-2NB3MB00000NSN 1047706
Control unit MCUP-SNB3CE00000NSN 1050340
Control unit MCUP-2NB3CE00000NSN 1050339
H = 300 (for ATEX zone 2 version
320 (for CSA CII Div 2 version
