SICK FLOWSIC100 Flare

Specifications
FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH 255
Subject to change without notice
Fig. 184 Wiring diagram for FLSE100-EXS/FLSE100-EXPR
Vervielfaeltigung dieser Unterlage sowie Verwertung und Mitteilung ihres Inhaltes unzulaessig, soweit nicht ausdruecklich zugestanden. Zuwiderhand- lungen sind strafbar und verpflichten zu Schadenersatz (LitUrhG, UWG, BGB). Alle Rechte fuer den Fall der Patenterteilung oder GM-Eintragung vorbehalten.
A4_Formblatt_ME10.CDR
SICK Engineering GmbH
Bergener Ring 27
01458 Ottendorf-Okrilla
Verteildatum: Page
Norm-Typ/DIN
Ersatz für:
Änderung
gepr. gez.
Tag
Name
Ind. Tag Name
Maßstab:
Werkstoff Ersetzt durch:
Gepr.
Ursprung:
2008-08-05 MKO
E_41943
3of6
Class I, Division 1, Groups C and D, Temp.Code T4, Class I, Division 2, Groups C and D, Temp.Code T4 Class I, Zone 1: Ex/AEx d[ia] IIB, Temp.Code T4, Class I, Zone 2: Ex/AEx nA[ia] IIB, Temp.Code T4
Coaxial Cable
Coaxial Cable
Coaxial Cable
MASTER
GND
+24V
A
B
SLAVE
GND
+24V
A
B
Coaxial Cable
Coaxial Cable
Coaxial Cable
MASTER
GND
+24V
A
B
SLAVE
GND
+24V
A
B
Temperature range and pressure range see Marking plate
Zone separating wall,
e.g. pipeline or duct
Kochan
Ultrasonic Transducers [Exia], mfg. by SICK only
Temperature Sensor [Exia], mfg. by SICK only
-50°C < Tamb <70°C, ambient pressure
AWG 12 AWG 12
Conduit size 1/2" NPT
AWG 16
AWG 16
AWG 16
AWG 16
Ultrasonic Transducers [Exia], mfg. by SICK only
Entity Parameters Voc = 51.2 V, Isc = 77 mA Ca < 18 nF, La < 0.03 mH Ci negligible, Li < 6.7 mH
Temperature Sensor [Exia], mfg. by SICK only
Entity Parameters Voc=8.6V,Isc=5mA Ca<5μF,La<1mH Ci, Li negligible
AWG20upto16
AWG20upto16
AWG20upto16
AWG20upto16
Manufacturer drawing FLSE100-EXS-C/-EXPR-C
Power supply T Data Interface
erminals +24V, GND
15...28 V dc, 500mA max.
(RS485)
Terminals A, B +/- 5 V, max. 500mA
TYPE 4, IP 65
2009-08-18
Division1 / Zone 0 / Zone 1 Installation 1. Maximum non hazardous area voltage not to exeed 125V 2. In the US install in accordance with the NEC (ANSI/NFPA 70)
and ANSI/ISA RP12.6
3. In Canada install in accordance with the CEC part 1 4. [Exia]
WARNING: Substitution of components may impair Intrinsic Safety
Division2 / Zone 2 Installation 2. In the US install in accordance with the NEC (ANSI/NFPA 70)
and ANSI/ISA RP12.6
3. In Canada install in accordance with the CEC part 1 5. WARNING: Explosion Hazard - Substitution may impair suitabilty
for Class I Division 2
6 1. This equipment is suitable for installation in Class I, Division 2,
Groups C and D hazardous locations or nonhazardous locations only.
4. WARNING: Explosion Hazard - Do not connect or disconnect
this equipment unless power has been switched off or the area is known to be nonhazardous.
. [Exia]
WARNING: Substitution of components may impair Intrinsic Safety
7. Maximum non hazardous area voltage not to exeed 125V
Kochan
MKO
A
2009-12-04
