Assembly and Installation
FLOWSIC100 Flare · Operating Instructions · 8013344/11L2/V 2-5/2018-10 · © SICK Engineering GmbH 85
Subject to change without notice
Fig. 34 Option mechanical support for nozzle "gusset plates"
NOTICE:
The plant operator is responsible for the safety of the system under mechanical
burden.
Gusset
