Table 96: Error codes and error messages in the Flexi Soft system and possible troubleshooting measures
LED display on the module Possible error
c
odes
Possible causes Possible measures
Main module
FX3-
CPUx
Expansion
module
1)
MS = Ö r
ed
(1Hz)
All expansion
module
s:
MS = Ö red
(1Hz) (firm‐
ware
≥V2.00.0)
or
MS = Ö red/
green (1Hz)
(firmware
V1.xx.0)
Main module:
0x000E4006,
0x00160005,
0x000F0013
The configuration in the system
plu
g is incompatible, because it is
intended for a different type of main
module:
•
The system plug has been previ‐
ously used in a system with a dif‐
ferent type of main module (e.g.,
FX3-CPU0 instead of FX3-CPU1,
or vice versa).
•
An incorrect main module has
been used in the hardware
installation.
•
T
ransfer a configuration with the
same type of main module as in
the hardware installation.
•
Replace the main module in the
hardware installation with a main
module of the same type as in
the project file.
Main module:
0x00170005,
0x000F0013
The configuration in the system
plu
g is incompatible, because it is
intended for more recent firmware
version of the main module:
•
The system plug has been
configured for an incompatible
more recent firmware version of
the main module (e.g., V2.00.0
instead of V1.11.0).
•
An older firmware version of the
main module has been used in
the hardware installation.
•
T
ransfer a configuration with the
same or an older firmware ver‐
sion (e.g, V1.xx.0 instead of
V2.xx.0).
•
Replace the main module in the
hardware installation with a mod‐
ule with a more recent or iden‐
tical firmware version as in the
project file.
Main module:
0x000E4013,
0x00274006
The configuration in the system plug
is inc
ompatible with at least one
expansion module:
•
An expansion module is missing
in the hardware installation.
•
T
ransfer a configuration with a
suitable number of expansion
modules.
•
Add the missing expansion mod‐
ule to the hardware installation.
Main module:
0x000E0006,
0x0005000D
FX3-
XTIO/-XTDI:
0x4901,
0x4904
The configuration in the system plug
is invalid:
•
The last configuration operation
was not completed successfully,
e.g., because the power supply
was switched off before the write
operation to the system plug was
completed.
•
Hardware error in system plug
•
The system plug is empty (condi‐
tion on delivery).
•
T
ransfer the configuration again
and make sure that the power
supply at the main module
remains switched on until the
transfer operation is complete.
•
Replace the system plug and
transfer the configuration again.
10 TROUBLESHOOTING
118
O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller 8012478/1IG6/2023-02-24 | SICK
Subject to change without notice
