LED display on the module Possible error
c
odes
Possible causes Possible measures
Main module
FX3-
CPUx
Expansion
module
1)
MS = Ö r
ed
(1Hz)
EFI = Ö red
(1Hz)
One or more
e
xpansion
modules:
MS = Ö red
(1Hz) (firm‐
ware
≥V2.00.0)
or
MS = Ö red/
green (1Hz)
(firmware
V1.xx.0)
Main module:
0x0014000A
If FX3-CPU1: EFI device address con‐
f
lict:
At least 2 main modules with
the same EFI address are con‐
nected.
Chan
ge the EFI address of the
main module or the connected
device in the configuration soft‐
ware.
Main module:
0x0015000A
If FX3-CPU1 and Flexi Link: incorrect
F
lexi Link ID:
EFI1 and EFI2 were mixed up
during wiring.
At least 1 main module with
an incorrect Flexi Link ID is con‐
nected.
Chec
k the wiring between the
Flexi Link stations: EFI1 must be
connected to EFI1 and, if appli‐
cable, EFI2 to EFI2.
Connect Flexi Link stations with
correct IDs.
Transfer the configuration to all
Flexi Link stations with the same
Flexi Link IDs.
Main module:
0x001F0006,
0x00230006,
0x00234006,
0x001F4006
The configuration in the system plug
is inc
ompatible with at least one
expansion module:
Incorrect module type or incor‐
rect module version (MS LED on
module is flashing red or red/
green).
Too many expansion modules
are connected. (MS LED on mod‐
ule is flashing red or red/green.)
Expansion modules are missing.
(MS LEDs on all other modules
are flashing red or red/green.)
T
ransfer a configuration with the
same module type and the same
or an older firmware version of
all expansion modules.
Replace the expansion module
affected in the hardware installa‐
tion with a module of the same
type and a firmware version that
is older than or identical to the
one in the project file.
MS = Ö
g
reen (1Hz)
CV = Ö yel‐
low (1Hz)
MS = Ö
green (1Hz)
The system is in the Stop state
(r
eady for operation).
The application can be started from
within the configuration software.
For automatic starting following
power-up, the project must be veri‐
fied with the configuration software.
MS = Ö
g
reen (1Hz)
CV = Ö yel‐
low
MS = Ö
green (1Hz)
The system is in the Stop state
(r
eady for operation).
The application can be started from
within the configuration software.
MS = Ö
g
reen
MS = Ö
green
The system is in operation. No errors
de
tected.
MS = Ö
g
reen
One or more
e
xpansion
modules:
MS = Ö red/
green (1Hz)
(firmware
≥V2.00.0)
or
MS = Ö red
(1Hz) (firm‐
ware V1.xx.0)
and
Q1 + Q2 + Q3
+ Q4 = Ö
green (1Hz)
FX3-XTIO:
0x4804,
0x4806,
0x4807
The supply voltage of an FX3-XTIO
module is t
oo low or is missing.
Check the power supply at terminals
A1 (24 V) and A2 (GND) on the FX3-
XTIO module, including under worst-
case conditions.
The error is reset automatically after
approx. 8 seconds if its cause is no
longer present.
TROUBLESHOOTING 10
8012478/1IG6/2023-02-24 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller
119
