SICK FX0-GMOD User Manual

UE410-2RO/UE410-4RO
Wire cross-section Single-wire or fine-stranded wire: 0.2 … 1.5mm²
St
randed wire with ferrule:
a) With plastic ferrule max. 0.75mm²
b) Without plastic ferrule max. 1.5mm²
AWG to UL/CUL: 24 … 16
Stripping length Max. 8mm
Tightening torque Max. 0.6Nm
For UL-508 and CSA applications
UE410-xx3…, UE410-
xxx3…
Cross-sectional area AWG 30-12
(use onl
y 60/75°C copper wire)
Tightening torque 5-7lb⋅in
UE410-xx4…, UE410-
xxx4…
Cross-sectional area AWG 30-12
(use only 60/75°C copper wire)
Electrical data
T
able 183: Input circuit (B1, B2) of the UE410-2RO/UE410-4RO
Minimum Typical Maximum
Input voltage ON 18V DC – 30V DC
Table 184: Output circuit (13-14, 23-24, 33-34, 43-44) of the UE410-2RO/UE410-4RO
Minimum Typical Maximum
Number of normally open contacts
UE410-2RO 2
UE410-4RO 4
Number of N/C contacts
UE410-2RO 1
UE410-4RO 2
AC switching voltage 5V AC 230V AC
1)
253V AC
DC switching voltage 5V DC 230V DC
1)
253V DC
Switching current 10mA – 6A
Mechanical service life Min. 10 ×10
6
Electrical endurance see figure 69, page 169
Minimum contact load at U
n
= 24V
DC
50mW – –
Sum current – – 8A
Response time
2)
– – 30ms
Type of output Volt-free normally open contacts, positively guided
Contact material AgSnO
2
Output circuit protection 6A gG, per current path
Utilization category AC-15: U
e
250V
, I
e
3A
DC-13: U
e
24V
, I
e
3A
1)
see figure 68, page 169 or see
figure 69, page 169.
2)
Time from low at B1/B2 to drop out of relay.
12 T
ECHNICAL DATA
168
O P E R A T I N G I N S T R U C T I O N S | Flexi Soft Modular Safety Controller 8012478/1IG6/2023-02-24 | SICK
Subject to change without notice
