Tag Description R/W
1
I/R/B
2
BV01..BV150 Boolean variable R B
FV01..FV20 Filter value R R
LV01..LV20 Limit value exceeded R
0 = within limit value
1 = limit value exceeded
B
Input/output interfaces
AO
i
(i=1..20) Physical value output (scaled) R R
AO
i
O
( i=1..20)
Direct value for current output 0..20 mA in mA R R
AO
i
OR
( i=1..20)
Current active display range R
0 = measuring range 1
1 = measuring range 2
B
AI
i
( i=1..48)
Read in and converted physical value R/W R
AI
i
I
( i=1..48)
Direct value for current input 0..20 mA in mA R/W R
DO
i
( i=1..128)
Triggering signal for digital output before an inversion that may be set R B
DO
i
O
( i=1..128)
Direct relay state for switching signal output R R B
DI
i
( i=1..64)
Input signal after an inversion that may be set R/W B
Heating control
HC
i
( i=1..2) Actual value (temperature) of the internal heating control i R R
HCPi
( i=1..2)
Actual value of internal PID heating control i in the configured unit R R
HCPiC
( i=1..2)
Actual value of internal PID heating control i in °C R R
1
R = read, W = write
2
I = integer value, R = real value, B = Boolean value
ANNEX 11
8017585/YXD9/V3-1/2017-05 | SICK T E C H N I C A L I N F O R M A T I O N | MARSIC300
101
Subject to change without notice
