SICK MLG-2 WebChecker User Manual

Service data Configuration module
Parameter name MLG-2 Data type Ether‐
CA
T
®
PROFINE
T
Ethernet/
IP
TM
PROFINE
T
Ethernet/
IP
TM
Size
Class
102
Class
153
Quality Sub 5 0x2294 135
Live edge 2 Struct 0x22A0 0x22A0 136
Live edge 3 0x22B0 0x22B0 141
Live edge 4 0x22C0 0x22C0 146
Live edge 5 0x22D0 0x22D0 151
Live edge 6 0x22E0 0x22E0 156
Live edge 7 0x22F0 0x22F0 161
Live edge 8 0x2300 0x2300 166
Live edge 9 0x2310 0x2310 171
Live edge 10 0x2320 0x2320 176
Search field 1 rw 0x2330 x x 4
Lower limit UINT16 Sub 1 0x2330 181 x x
Upper limit Sub 2 0x2331 182 x x
Search field 2 Struct 0x2340 0x2340 183 x x 4
Search field 3 0x2350 0x2350 185 x x 4
Search field 4 0x2360 0x2360 187 x x 4
Search field 5 0x2370 0x2370 189 x x 4
Search field 6 0x2380 0x2380 191 x x 4
Search field 7 0x2390 0x2390 193 x x 4
Search field 8 0x23A0 0x23A0 195 x x 4
Search field 9 0x23B0 0x23B0 197 x x 4
Search field 10 0x23C0 0x23C0 199 x x 4
Q1 configuration 0x23D0 x x 2
inverted Bool Sub 1 0x23D0 201
Output function UINT8 Sub 2 0x23D1 202
Q2 configuration Struct rw 0x23E0 0x23E0 203 x x 2
Q3 configuration 0x23F0 0x23F0 205 x x 2
Q4 configuration 0x2400 0x2400 207 x x 2
Q5 configuration 0x2410 0x2410 209 x x 2
Q6 configuration 0x2420 0x2420 211 x x 2
Q7 configuration 0x2430 0x2430 213 x x 2
Q8 configuration 0x2440 0x2440 215 x x 2
Q9 configuration 0x2450 0x2450 217 x x 2
Q10 configuration 0x2460 0x2460 219 x x 2
Q11 configuration 0x2470 0x2470 221 x x 2
Q12 configuration 0x2480 0x2480 223 x x 2
Q13 configuration 0x2490 0x2490 225 x x 2
Q14 configuration 0x24A0 0x24A0 227 x x 2
Q15 configuration 0x24B0 0x24B0 229 x x 2
Q6 configuration 0x24C0 0x24C0 231 x x 2
10 THE MLG-2 WEBCHECKER IN THE FIELDBUS NETWORK
84
O P E R A T I N G I N S T R U C T I O N S | MLG-2 WebChecker 8025190/2020-01-13 | SICK
