Digital Modules
3-53
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
3.18 Digital Output Module SM 322;
DO 16 x DC 24 V/ 0.5 A; (6ES7322-1BH01-0AA0)
Order number: “Standard module”
6ES7322-1BH01-0AA0
Order number: “SIPLUS S7-300-Module”
6AG1322-1BH01-2AA0
Characteristics
The digital output module SM 322; DO 16 x 24 VDC/0.5 A has the following salient
features:
• 16 outputs, isolated in groups of 8
• 0.5 A output current
• 24 VDC rated load voltage
• Suitable for solenoid valves, DC contactors and indicator lights
Using the module with high-speed counters
Please take note of the following information on the use of the module in
connection with high-speed counters:
Note
When connecting the 24 V power supply via a mechanical contact, the outputs of
the SM 322; DO 16 x 24 VDC/0.5 A carry a “1” signal for approximately 50 s for
reasons associated with the circuitry.
