Digital Modules
3-81
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
3.24 Digital Output Module SM 322; DO 8 x VDC 48-125/1,5 A;
(6ES7322-1CF00-0AA0)
Order number: “Standard module”
6ES7322-1CF00-0AA0
Order number: “SIPLUS S7-300-Module”
6AG1322-1CF00-2AA0
Characteristics
The SM 322; DO 8 x 48-125 VDC/1.5 A features the following characteristics:
• 8 outputs, reverse polarity protection and isolated in groups of 4
• 1.5 A output current
• Rated load voltage 48 to 125 VDC
• Suitable for solenoid valves, DC contactors and indicator lights
• Group error display
Using the module with high-speed counters
Please take note of the following information on the use of the module in
connection with high-speed counters:
Note
When connecting the power supply via a mechanical contact, the outputs of the
SM 322; DO 8 x 48-125 VDC/1.5 A carry a “1” signal for approximately 50 s for
reasons associated with the circuitry.
