C-4
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
160 mm rail
Figure C-5 shows the dimension drawing of the 160 mm rail.
14010
57.2 32.5
160
15
6
122
7
10
M6
Figure C-5 Dimension Drawing of the Rail with 160 mm Standard Width
482.6 mm rail
Figure C-6 shows the dimension drawing of the 482.6 mm rail.
8.3
15
6
466
57.2 32.5
482.6
122
7
10
M6
Figure C-6 Dimension Drawing of the Rail with 482.6 mm Standard Width
