Power Supply Modules
2-11
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Line protection
We recommend that you install a miniature circuit-breaker (MCB) (for example
Siemens 5SN1 series) with the following rating to protect the incoming supply
cable of the PS 307 power supply module (5 A):
• Rated current at 230 VAC: 10 A
• Tripping characteristic (type): C.
Reaction to atypical operating conditions
Table 2-3 Reaction of the PS 307 Power Supply Module (5 A) to Atypical Operating
Conditions
If ...
... Then ... 24 VDC
LED
... the output circuit is overloaded:
• I > 6.5 A (dynamic)
• 5 A < I v 6.5 A (static)
Voltage dip, autom. volt. recovery
Voltage drop, shortening of service life
Flashes
... the output is short-circuited Output voltage 0 V; automatic voltage recovery
after short circuit has been eliminated
Dark
An overvoltage occurs on the primary
side
Possible destruction –
There is an undervoltage on the
primary side
Automatic disconnection; automatic voltage
recovery
Dark
