Digital Modules
3-6
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Table 3-3 Digital Output Modules: Characteristics at a Glance
Module
Char-
acter-
istics
SM 322;
DO 32 x
24 VDC
0.5 A
(-1BL00-)
SM 322;
DO 32 x
VAC 120/230/
1 A
(-1FL00-)
SM 322;
DO 16 x
24 VDC/
0.5 A
(-1BH01-)
SM 322;
DO 16 x
24 VDC/
0.5 A High
Speed
(-1BH10-)
SM 322;
DO 16 x
24/48 VUC
(-5GH00-)
SM 322;
DO 16 x
120/230 VDC/
1 A
(-1FH00-)
Number of outputs 32 DO;
isolated in
groups of 8
32 DO;
isolated in
groups of 8
16 DO;
isolated in
groups of 8
16 DO;
isolated in
groups of 8
16 DO;
isolated in
groups of 1
16 DO;
isolated in
groups of 8
Output current 0.5 A 1.0 A 0.5 A 0.5 A 0.5 A 0.5 A
Rated load voltage 24 VDC 120 VAC 24 VDC 24 VDC 24 to 48 VDC,
24 to 48 VAC
120/230 VAC
Suitable for... Solenoid valves, DC contactors and indicator lights
Supports
clocked operation
No No No Yes No No
Programmable
diagnostics
No No No No Yes No
Diagnostic
interrupt
No No No No Yes No
Substitute value
output
No No No No Yes No
Special Features –
