Page #140 background image
Digital Modules
3-56
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
3.19 Digital Output Module SM 322; DO 16 x 24 VDC/0.5 A
High Speed;
(6ES7322-1BH10-0AA0)
Order number:
6ES7322-1BH10-0AA0
Characteristics
The SM 322; DO 16 x 24 VDC/0.5 A High Speed has the following salient features:
16 outputs, isolated in groups of 8
0.5 A output current
24 VDC rated load voltage
Suitable for solenoid valves, DC contactors and indicator lights
Supports clocked operation
Using the module with high-speed counters
Please take note of the following information on the use of the module in
connection with high-speed counters:
Note
When connecting the 24 V power supply via a mechanical contact, the outputs of
the SM 322; DO 16 x 24 VDC/0.5 A High Speed carry a “1” signal for
approximately 50 s for reasons associated with the circuitry.
