Digital Modules
3-120
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Structure of data record 1
The following figure shows the structure of data record 1 of the dynamic
parameters of the SM 327; DI 8/DX 8 x DC 24 V/0.5 A.
Byte 0
Byte 5
1: Use channel 8 as output
0: Use channel 8 as input
+1: Use channel 15 as output
0: Use channel 15 as input
Byte 1
Byte 2
Byte 3
Byte 4
Not relevant
Not relevant
Not relevant
Not relevant
Not relevant
...
...
...
...
...
...
Figure 3-40 Data record 1 of the SM 327; DI 8/DX 8 x VDC 24/0.5 A
