Parameter Sets for Signal Modules
A-39
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
A.10 Parameters of the SM 332; AO 8 x 12 bits
Parameters
Table A-28 contains all the parameters that you can set for the analog output
module SM 332; AO 8 x 12 bits. The comparison shows:
• Which parameters you can change with STEP 7 and
• Which parameters you can change with SFC 55 “WR_PARM”.
The parameters which you set with STEP 7 can also be transferred to the module
with SFCs 56 and 57.
Table A-30 Parameters of the SM 332; AO 8 x 12 bits.
Parameter
Data Record
No.
Parameters can be assigned
with ...
... SFC 55 ...
Programming
Device
Diagnostics: Group diagnostics 0 No Yes
Diagnostics interrupt enable Yes Yes
Behavior on CPU STOP
Yes Yes
Output type
Yes Yes
Output Range Yes Yes
Note
If you want to enable the diagnostic interrupt in the user program in data record 1,
you must enable the diagnosis in data record 0 beforehand using STEP 7.
