Digital Modules
3-69
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
3.22 Digital Output Module SM 322; DO 8 x 24 VDC/2 A;
(6ES7322-1BF01-0AA0)
Order number
6ES7322-1BF01-0AA0
Characteristics
The digital output module SM 322; DO 8 x 24 VDC/2 A has the following salient
features.
• 8 outputs, isolated in groups of 4
• 2 A output current
• 24 VDC rated load voltage
• Suitable for solenoid valves, DC contactors and indicator lights
Using the module with high-speed counters
Please take note of the following information on the use of the module in
connection with high-speed counters:
Note
When connecting the 24 V power supply via a mechanical contact, the outputs of
the SM 322; DO 8 x 24 VDC/2 A carry a “1” signal for approximately 50 s for
reasons associated with the circuitry.
