Parameter Sets for Signal Modules
A-7
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
A.4 Parameters of the Analog Input Modules
Parameters
The table below contains all the parameters you can set for analog input modules.
You will see which parameters you can modify from the list:
• In STEP 7
• With SFC 55 “WR_PARM”
The parameters set with STEP 7 can also be transferred with SFCs 56 and 57 to
the module (refer to the STEP 7 manuals).
Table A-4 Parameters of the Analog Input Modules
Parameter
Data Record
No.
Parameters can be assigned
with ...
... SFC 55 ...
Programming
Device
Diagnostics: Group diagnostics No Yes
Diagnostics: With wire-break check No Yes
Temperature unit
0
No Yes
Temperature coefficient
0
No Yes
Smoothing No Yes
Diagnostics interrupt enable Yes Yes
Limit value interrupt enable Yes Yes
Cycle end interrupt enable Yes Yes
Interference Suppression
1
Yes Yes
Measuring Method
1
Yes Yes
Measuring Range Yes Yes
Upper limit value Yes Yes
Lower limit value Yes Yes
Note
If you want to enable the diagnostic interrupt in the user program in data record 1,
you must enable the diagnosis in data record 0 beforehand using STEP 7.
