Parameter Sets for Signal Modules
A-43
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Measuring methods and measuring ranges
The table below contains all the measuring methods and measuring ranges of the
analog input/output modules and their codes. You must enter these codes in bytes
2 to 5 of data record 1 (refer to Figure A-19).
Table A-33 Codes for the Measuring Ranges of the Analog Input/Output Modules
Measuring Method
Code Measuring Range Code
Deactivated 2#0000 Deactivated 2#0000
Voltage 2#0001 0 to 10 V 2#1000
Resistance, four-conductor connection 2#0100 10 k 2#1001
Thermal resistance + linearization
four-conductor connection
2#1000 Pt 100 climate 2#0000
Output methods and output ranges
The table below contains all the output methods and output ranges of the analog
input/output modules and their codes. You must enter these codes in bytes 6 and 7
of data record 1 (refer to Figure A-19).
Table A-34 Codes for the Output Ranges of the Analog Input/Output Modules
Output type
Code Output Range Code
Deactivated 2#0000 Deactivated 2#0000
Voltage 2#0001 0 to 10 V 2#1000
