C-18
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
SIMATIC TOP connect, 1-tier
Figure C-24 shows the dimension drawing of the 1-tier SIMATIC TOP connect.
55
52
40.5
35.5
35
Figure C-24 SIMATIC TOP connect, 1-tier
RS 485 repeater on standard rail
Figure C-25 shows the dimension drawing of the RS 485 repeater on the standard
rail.
73
125
128
45
Figure C-25 RS 485 Repeater on Standard Rail
