6.3 Interface Module IM 361; (6ES7361-3CA01-0AA0)
Order number
6ES7361-3CA01-0AA0
Characteristics
The interface module IM 361 has the following characteristic features:
• 24 VDC power supply
• Interface for racks 1 to 3 of the S7-300
• Current output via the S7-300 backplane bus max. 0.8 A
• Data transfer from the IM 360 to the IM 361 or from the IM 361 to the IM 361
via connecting cable 368
• Maximum distance between IM 360 and IM 361 is 10 m (32.8 ft.)
• Maximum distance between IM 361 and IM 361 is 10 m
Status and fault LEDs
The interface module IM 361 has the following status and fault LEDs.
LED Meaning Explanation
SF Group error/fault The LED lights up if
• the connecting cable is
missing
• the series-connected
IM 361 is switched off
• the CPU is in the
POWER OFF state
5 VDC 5 VDC supply for the S7-300
backplane bus
–
