Digital Modules
3-76
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
3.23.1 Assigning Parameters to the SM 322; DO 8 x 24 VDC/0.5 A
Parameter assignment
You will find a description of the general procedure for assigning parameters to
digital modules in Section 3.3.
Parameters of the SM 322; DO 8 x 24 VDC/0.5 A
You will find an overview of the parameters that you can set and their default
settings for the SM 322; DO 8 x 24 VDC/0.5 A in the table below.
The default settings apply if you have not performed parameter assignment in
STEP 7.
Table 3-18 Parameters of the SM 322; DO 8 x 24 VDC/0.5 A
Parameter
Value Range Default
Settings
Parameter
Type
Scope
Enable
• Diagnostic interrupt Yes/no No Dynamic Module
Behavior on CPU STOP Apply substitute value (EWS)
Hold last value (LWH)
EWS
Diagnostics
• Wire-break
• No load voltage L+
• Short-circuit to M
• Short-circuit to L+
Yes/no
Yes/no
Yes/no
Yes/no
No
No
No
No
Static Channel
Apply substitute value “1” Yes/no No Dynamic Channel
