Parameter Sets for Signal Modules
A-5
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
A.3 Parameters of the Digital Output Modules
Parameters
The table below contains all the parameters you can set for digital output modules.
Note
For details of the parameters of parameterized digital input/output modules, see
the respective chapter of the module concerned.
You will see which parameters you can modify from the list:
• In STEP 7
• With SFC 55 “WR_PARM”
• With SFB 53 “WRREC” (e. g. for GSD).
The parameters set with STEP 7 can also be transferred with SFCs 56 and 57 and
the SFB 53 to the module (refer to the STEP 7 manuals).
Table A-3 Parameters of the Digital Output Modules
Parameter
Data Record
No.
Parameters can be assigned
with ...
... SFC 55,
SFB 53
...
Programming
Device
Diagnosis of missing load voltage L+ No Yes
Diagnosis of broken wire
No Yes
Diagnosis of short–circuit to M
No Yes
Diagnosis of short–circuit to L+ No Yes
Diagnostics interrupt enable Yes Yes
Behavior on CPU STOP
1
Yes Yes
Enable substitute value “1”
Yes Yes
Note
If you want to enable the diagnostic interrupt in the user program in data record 1,
you must enable the diagnosis in data record 0 beforehand using STEP 7.
