A-36
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Table A-27 Codes for the smoothing mode settings of the SM 331;
AI 8 x 16 bits
Smoothing mode setting Code
None 2#00
Low 2#01
Average 2#10
High 2#11
A.9 Parameters of the Analog Output Modules
Parameters
Table A-28 contains all the parameters you can set for analog output modules..
The comparison shows:
• Which parameters you can change with STEP 7 and
• Which parameters you can change with SFC 55 “WR_PARM”.
The parameters which you set with STEP 7 can also be transferred to the module
with SFCs 56 and 57.
Table A-28 Parameters of the Analog Output Modules
Parameter
Data Record
No.
Parameters can be assigned
with ...
... SFC 55 ...
Programming
Device
Diagnostics: Group diagnostics 0 No Yes
Diagnostics interrupt enable Yes Yes
Behavior on CPU STOP Yes Yes
Output type
1
Yes Yes
Output Range
Yes Yes
Substitute value Yes Yes
Note
If you want to enable the diagnostic interrupt in the user program in data record 1,
you must enable the diagnosis in data record 0 beforehand using STEP 7.
