Digital Modules
3-110
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
3.31 Digital Input/Output Module SM 323;
DI 16/DO 16 x 24 VDC/0.5 A; (6ES7323-1BL00-0AA0)
Order number
6ES7323-1BL00-0AA0
Characteristics
The SM 323; DI 16/DO 16 x 24 VDC/0.5 A features the following characteristics:
• 16 inputs, isolated in groups of 16
• 16 outputs, isolated in groups of 8
• 24 VDC rated input voltage
• 24 VDC rated load voltage
• Inputs suitable for switches and two / three / four-wire BEROs (proximity
switches)
• Outputs suitable for solenoid valves, DC contactors and indicator lights
Using the module with high-speed counters
Please take note of the following information on the use of the module in
connection with high-speed counters:
Note
When connecting the 24 V power supply via a mechanical contact, the outputs of
the SM 323; DI 16/DO 16 x 24 VDC/0.5 A carry a “1” signal for approximately
50 s for reasons associated with the circuitry.
