Digital Modules
3-93
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
3.27 Relay Output Module SM 322;
DO 16 x Rel. 120/230 VAC; (6ES7322-1HH01-0AA0)
Order number
6ES7322-1HH01-0AA0
Characteristics
The SM 322; DO 16 x Rel. 120/230 VAC features the following characteristics:
• 16 outputs, isolated in groups of 8
• Rated load voltage 24 VDC to 120 VDC, 48 VAC to 230 VAC
• Suitable for AC/DC solenoid valves, contactors, motor starters, fractional h.p.
motors and indicator lights.
Behavior upon power down of the supply voltage
Note
When the power supply is switched off, the capacitor still stores energy for
about 200 ms. The relay can therefore still be driven briefly within this time by the
user program.
