Page #197 background imageLoading...
Page #197 background image
Digital Modules
3-113
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
3.32 Digital Input/Output Module SM 323;
DI 8/DO 8 x VDC 24/0.5 A; (6ES7323-1BH01-0AA0)
Order number: “Standard module”
6ES7323-1BH01-0AA0
Order number: “SIPLUS S7-300-Module”
6AG1323-1BH01-2AA0
Characteristics
The SM 323; DI 8/DO 8 x 24 VDC/0.5 A features the following characteristics:
8 inputs, isolated in groups of 8
8 outputs, isolated in groups of 8
24 VDC rated input voltage
24 VDC rated load voltage
Inputs suitable for switches and two / three / four-wire BEROs (proximity
switches)
Outputs suitable for solenoid valves, DC contactors and indicator lights
Using the module with high-speed counters
Please take note of the following information on the use of the module in
connection with high-speed counters:
Note
When connecting the 24 V power supply via a mechanical contact, the outputs of
the SM 323; DI 8/DO 8 x 24 VDC/0.5 A carry a “1” signal for approximately 50 s
for reasons associated with the circuitry.
