Siemens 6ES7 305-1BA80-0AA0 Reference Manual

Digital Modules
3-114
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Terminal assignment and block diagram of the SM 323; DI 8/DO 8 x 24 VDC/0.5 A
Status display – green
Channel number
Backplane bus
interface
1M
2M
24V
24V
2L+
M
Figure 3-38 Module View and Block Diagram of Digital Input/Output Module SM 323;
DI 8/DO 8 x 24 VDC/0.5 A

Siemens 6ES7 305-1BA80-0AA0 Specifications

General

Brand	Siemens
Model	6ES7 305-1BA80-0AA0
Category	Controller
Language	English
