Dimension Drawings
C-17
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
SIMATIC TOP connect, 3-tier
Figure C-22 shows the dimension drawing of the 3-tier SIMATIC TOP connect.
70
60 40.5
35.5
35
Figure C-22 SIMATIC TOP connect, 3-tier
SIMATIC TOP connect, 2-tier
Figure C-23 shows the dimension drawing of the 2-tier SIMATIC TOP connect.
70
60 40.5
35.5
35
Figure C-23 SIMATIC TOP connect, 2-tier
