Analog Modules
4-44
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
4.7.3 Parameters of the analog input/output modules
The analog input/output modules make available the parameters in the following
table. The default settings apply if you have not performed parameter assignment
in STEP 7.
Table 4-43 Parameters of the Analog Input/Output Modules
Parameter
Value Range Default
Settings
Para-
meter
Type
Scope
Input
Measurement
• Measuring
method
Deactivated
U Voltage
R-4L Resistance
(four-conductor connection)
RTD-4L Bulb resistor (linear,
four-conductor connection)
RTD-4L
Dynamic Channel
• Measuring Range 0 to 10 V
10000
Pt 100 climate
Pt 100
climate
• Integration time 20 ms; 16.6 ms 20 ms
Output
• Output type Deactivated
Voltage
U
Dynamic Channel
• Output range 0 to 10 V 0 to 10 V
