Siemens 6ES7 305-1BA80-0AA0 Reference Manual

Dimension Drawings
C-11
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
PS 307; 5 A with CPUs 313/314/315/315-2 DP
Figures C-15 and C-16 show the dimension drawings of the configuration of a
power supply module PS 307; 5 A with the CPUs 313/314/315/315-2 DP. Observe
the dimensions that result from the use of the power connector for wiring the
PS 307; 5 A with the CPU.
27
68
132
Figure C-15 Dimension Drawing of the Power Supply Module PS 307; 5 A with CPUs
313/314/315/315-2 DP. Front View
