Siemens 6ES7 305-1BA80-0AA0 Reference Manual

Digital Modules
3-57
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Terminal assignment and block diagram of the SM 322; DO
16 x 24 VDC/0.5 A
High Speed
Backplane bus
interface
1M
2M
24 V
M
24 V
1 L+
2 L+
Channel number
Status display – green
Figure 3-21 Module View and Block Diagram of the SM 322; DO 16 x 24 VDC/0.5 A High Speed

Siemens 6ES7 305-1BA80-0AA0 Specifications

General

Brand	Siemens
Model	6ES7 305-1BA80-0AA0
Category	Controller
Language	English
