Digital Modules
3-116
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
3.33 Digital Input/Output Module SM 327;
DI 8/DX 8 x DC 24 V/0.5 A; parameterizable
(6ES7327-1BH00-0AB0)
Order number
6ES7327-1BH00-0AB0
Characteristics
The SM 327; DI 8/DX 8 VDC 24/0.5 A features the following characteristics:
8 digital inputs and 8 individual parameterizable inputs or outputs, isolated in
groups of 16
24 VDC rated input voltage
Inputs suitable for switches and two / three / four-wire BEROs (proximity
switches)
0.5 A output current
24 VDC rated load voltage
Outputs suitable for solenoid valves, DC contactors and indicator lights
The parameters of the module can be dynamically changed-channel during the
RUN (CiR-capable)
Re-readability of the outputs.
Using the module with high-speed counters
Please take note of the following information on the use of the module in
connection with high-speed counters:
Note
When connecting the 24 V power supply via a mechanical contact, the outputs of
the SM 327; DI 8/DX 8 x DC 24 V/0.5 A carry a “1” signal for approximately 50 s
for reasons associated with the circuitry.
