Siemens 6ES7 305-1BA80-0AA0 Reference Manual

Analog Modules
4-25
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Table 4-32 Bipolar Output Ranges
Units
Output
Value in %
Data Word Range
Value in %
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
w32512 0 % 0 1 1 1 1 1 1 1 x x x x x x x x Overflow
32511 117.589 0 1 1 1 1 1 1 0 1 1 1 1 1 1 1 1 Over
range
27649 w100.004 0 1 1 0 1 1 0000000001
range
27648 100.000 0 1 1 0 1 1 0 0 0 0 0 0 0 0 0 0
1 0.003617 0 0 0 0 0 0 0000000001
0 0.000 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 Rated
range
–1 –0.003617 1 1 1 1 1 1 1111111111
range
–27648 –100.000 1 0 0 1 0 1 0000000000
–27649 v100.004 1 0 0 1 0 0 1 1 1 1 1 1 1 1 1 1 Under
range
–32512 –117.593 1 0 0 0 0 0 0100000000
range
v32513 0 % 1 0 0 0 0 0 0 0 x x x x x x x x Underflow
Table 4-33 Unipolar Output Ranges
Units
Output
Value in %
Data Word Range
Value in %
2
15
2
14
2
13
2
12
2
11
2
10
2
9
2
8
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
w32512 0 % 0 1 1 1 1 1 1 1 x x x x x x x x Over-
flow
32511 117.589 0 1 1 1 1 1 1 0 1 1 1 1 1 1 1 1 Over-
range
27649 w100.004 0 1 1 0 1 1 0000000001
range
27648 100.000 0 1 1 0 1 1 0 0 0 0 0 0 0 0 0 0
1 0.003617 0 0 0 0 0 0 0000000001Rated
range
0 0.000 0 0 0 0 0 0 0000000000
–1
0.000
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 Limited
to rated
range
lower
limit 0 V
–32512 1 0 0 0 0 0 0100000000
lower
limit 0 V
and
0 mA
v32513 0 % 1 0 0 0 0 0 0 0 x x x x x x x x Under-
flow
