Interface Modules
6-7
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Technical specification
The following overview lists the technical specifications for the interface module
IM 361.
Dimensions and Weight
Dimensions W x H x D
(in millimeters)
80 x 125 x 120
Weight 505 g
Data for Specific Module
Length of cable
Maximum length to next IM
10 m
Current consumption
From 24 VDC
Power loss
0.5 A
typ. 5 W
Current output
To backplane bus
0.8 A
Status and fault LEDs Yes
6.4 Interface Module IM 365; (6ES7365-0BA01-0AA0)
Order number: “Standard module”
6ES7365-0BA01-0AA0
Order number: “SIPLUS S7-300-Module”
6AG1365-0BA01-2AA0
Characteristics
The interface module IM 365 has the following characteristic features:
• Pre-assembled pair of modules for rack 0 and rack 1
• Total power supply of 1.2 A, of which up to 0.8 A can be used per rack.
• Connecting cable with a length of 1 m already permanently connected
• Install only signal modules in rack 1
• IM 365 does not forward the C bus to rack 1, i.e. you cannot plug FMs with a
C bus function in rack 1.
