Parameter Sets for Signal Modules
A-17
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Table A-10 Codes for the Measuring Ranges of the SM 331; AI 8 x RTD, continued
Measuring Method CodeMeasuring RangeCode
Thermal
resistance + linearization
four-conductor connection
2#1000 Pt 100 climate
Ni 100 climate
Pt 100 standard
Ni 100 standard
Pt 500 standard
Pt 1000 standard
Ni 1000 standard
Pt 200 climate
Pt 500 climate
Pt 1000 climate
Ni 1000 climate
Pt 200 standard
Ni 120 standard
Ni 120 climate
Cu 10 climate
Cu 10 standard
Ni 200 standard
Ni 200 climate
Ni 500 standard
Ni 500 climate
2#00000000
2#00000001
2#00000010
2#00000011
2#00000100
2#00000101
2#00000110
2#00000111
2#00001000
2#00001001
2#00001010
2#00001011
2#00001100
2#00001101
2#00001110
2#00001111
2#00010000
2#00010001
2#00010010
2#00010011
Thermal resistance +
linearization three-conductor
connection
2#1001 Pt 100 climate
Ni 100 climate
Pt 100 standard
Ni 100 standard
Pt 500 standard
Pt 1000 standard
Ni 1000 standard
Pt 200 climate
Pt 500 climate
Pt 1000 climate
Ni 1000 climate
Pt 200 standard
Ni 120 standard
Ni 120 climate
Cu 10 climate
Cu 10 standard
Ni 200 standard
Ni 200 climate
Ni 500 standard
Ni 500 climate
2#00000000
2#00000001
2#00000010
2#00000011
2#00000100
2#00000101
2#00000110
2#00000111
2#00001000
2#00001001
2#00001010
2#00001011
2#00001100
2#00001101
2#00001110
2#00001111
2#00010000
2#00010001
2#00010010
2#00010011
