Power Supply Modules
2-8
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Technical specifications of the PS 307; 2 A (6ES7307-1BA00-0AA0)
Dimensions and Weight
Dimensions W H D
(in millimeters)
50 125 120
Weight Approx. 420 g
Input Rating
Input voltage
• Rated value
System frequency
• Rated value
• Permitted range
120 / 230 VAC
50 Hz or 60 Hz
47 Hz to 63 Hz
Rated input current
• At 230 V
• At 120 V
0.5 A
0.8 A
Inrush current (at 25°C) 20 A
I
2
t (at inrush current) 1 A
2
s
Output Rating
Output voltage
• Rated value
• Permitted range
• Ramp-up time
24 VDC
24 V " 5 %, stable at
no load
max. 2.5 s
Output current
• Rated value
2 A,
Cannot be connected in
parallel
Short-circuit protection Electronic, nonlatching,
1.1 to 1.3 x I
N
Residual ripple max. 150 mV
ss
Other Parameters
Protection class according to
IEC 536 (DIN VDE 0106, Part
1)
I, with protective
grounding conductor
Insulation
• Rated insulation level
(24 V to L1)
• Tested with
250 VAC
2800 VDC
Reliable isolation SELV circuit
Bridging of power failures (at 93
and/or 187 V)
• Repeat rate
min. 20 ms
min 1 s
Efficiency 83 %
Power input 58 W
Power loss typ. 10 W
Diagnostics
LED for output voltage available Yes, green LED
