Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Technical specifications of the PS 307; 5 A (6ES7307-1EA80-0AA0)
Dimensions and Weight
Dimensions W x H x D
(in millimeters)
80 x 125 x 120
Weight Approx. 570 g
Input Rating
Input voltage
• Rated value 120/230 VDC
System frequency
• Rated value
• Permitted range
50 Hz or 60 Hz
47 Hz to 63 Hz
Rated input current
• At 120 V
• At 230 V
2.1 A
1.2 A
Inrush current (at 25 C) 45 A
I
2
t (at inrush current) 1.8 A
2
s
Output Rating
Output voltage
• Rated value
• Permitted range
• Ramp-up time
24 VDC
24 V " 3 %
max. 3 s
Output current
• Rated value 5 A; cannot be
connected in parallel
Short-circuit protection Electronic,
nonlatching,
from 1.1 to 1.3 x I
N
Residual ripple max. 150 mV
ss
Other Parameters
Protection class according to
IEC 536 (DIN VDE 0106, Part
1)
I, with protective
grounding conductor
Insulation
• Rated insulation level
(24 V to L1)
• Tested with
250 VAC
2800 VDC
Reliable isolation SELV circuit
Bridging of power failures (at 93
and/or 187 V)
• Repeat rate
min. 20 ms
min. 1 s
Efficiency 84%
Power input 143 W
Power loss 23 W
Diagnostics
LED for output voltage available Yes, green LED
