SIEMENS Energy & Automation 10-1
SIMOREG DC Master Base Drive Panel Operating Instructions
10 Parameter list
Overview
The Base Drive Panel Operating Instructions does not contain information about all available
parameters. Only the parameters mentioned in this book are included. For a complete list of
parameters please refer to power module Operating Instructions 6RX1700-0AD76.
Range of parameter numbers Function
r000 Operating display
r001 - P050 General visualization parameters
P051- r059 Access authorization levels
r060 - r065 Definition of SIMOREG DC MASTER converter
P067 - P079 Definition of SIMOREG DC MASTER power section
P080 - P098 Setting values for converter control
P100 - P139 Definition of motor
P140 - P148 Definition of pulse encoder, speed sensing using pulse encoder
P150 - P165 Closed-loop armature current control, auto-reversing stage, armature gating unit
P169 - P191 Current limitation, torque limitation
P192 Auto-reversing stage, armature gating unit
P200 - P236 Speed controller (further parameters for the speed controller P550 - P567)
P250 - P265 Closed-loop field current control, field gating unit
P272 - P284 Closed-loop EMF control
P295 - P319 Ramp-function generator
P320 - P323 Setpoint processing
P330 Ramp-function generator
P351 - P364 Setting values for monitoring functions and limits
P370 - P399 Setting values for limit-value monitors
P401 - P416 Settable fixed values
P421 - P428 Fixed control bits
P430 - P445 Digital setpoint input (fixed setpoint, inching and crawling setpoints)
P450 - P453 Position sensing with pulse encoder
P455 - P458 Connector selector switches
P460 - P473 Motorized potentiometer
P480 - P485 Oscillation
P490 - P498 Definition of "Motor interface”
P500 - P503 Configuring of torque shell input
P509 - P515 Speed limiting controller
P519 - P530 Friction compensation
P540 - P546 Compensation of moment of inertia (dv/dt injection)
P550 - P567 Speed controller (further parameters for the speed controller P200 - P236)
P580 - P583 Field reversal
P590 - P597 Input quantities for signals
P600 - P647 Configuring of closed-loop control
P648 - P691 Control word, status word
P692 - P698 Further configuring measures
P700 - P746 Analog inputs (main actual value, main setpoint, selectable inputs)
P749 - P769 Analog outputs
P770 - P778 Binary outputs
P780 - P819 Configuration of serial interfaces on basic converter
P820 - P821 Deactivation of monitoring functions
r824 - r829 Compensation values
P830 Thyristor diagnosis
