Siemens Energy & Automation 3-3
SIMOREG DC Master Base Drive Panel Operating Instructions
3.3 Option Part Numbers
Options Order No.
Terminal expansion card (CUD2) 6RX1700-0AK00
User-friendly operator control panel (OP1S) 6SE7090-0XX84-2FK0
AOP1 adapter for mounting OP1A in cubicle door, including
5 m connecting cable
6SX7010-0AA00
PMU-OP1S connecting cable, 3m 6SX7010-0AB03
PMU-OP1S connecting cable, 5m 6SX7010-0AB05
LBA Local bus adapter for the electronics box
Note: LBA is needed to install any boards listed below
6SE7090-0XX84-4HA0
ADB Adapter board
Note: ADB is always needed to install CBC, CBP2, CBD,
EB1, EB2, SBP and SLB boards
6SE7090-0XX84-0KA0
SBP Pulse encoder evaluation board
1) 2)
6SX7010-0FA00
EB1 Terminal expansion board
2)
6SX7010-0KB00
EB2 Terminal expansion board
2)
6SX7010-0KC00
SLB SIMOLINK board
2)
6SX7010-0FJ00
CBP2 Communications board interface for PROFIBUS
2)
6SX7010-0FF05
CBC Communications board interface for CAN protocol
2)
6SX7010-0FG00
CBD Communications board interface for DeviceNet protocol
2)
6SX7010-0FK00
T400 Technology board with SPW 420 Axial winder software 2) 6DD1-842-0AA0
T400 Technology board with SPW 440 Angular Synchr. Software 2) 6DD1-842-0ABO
1) A pulse encoder evaluation circuit is a standard component of the basic SIMOREG converter. The SBP only
needs to be ordered in configurations requiring evaluation of a second pulse encoder.
2) The LBA local bus adapter and ADB adapter board must be ordered as additional components for installing
supplementary boards in the SIMOREG converter.
