10-12 SIEMENS Energy & Automation
SIMOREG DC Master Base Drive Panel Operating Instructions
PNU
Description Value range
[Unit]
Steps
No. indices
Factory
setting
Type
See
Change
(Access /
Status)
P053
*
Control word for the permanent memory [SW 1.7 and later]
Disabling or enabling write accesses to the permanent memory
i001: Disabling or enabling write accesses to the parameter memory
0 Only save parameter P053 in the permanent memory;
parameter changes are active immediately but the changed
values are only stored temporarily and are lost when the
electronics supply voltage is switched off
1 Save all parameter values in the permanent memory
i002: Disabling or enabling write accesses to the memory of the
nonvolatile process data
0 Do not save nonvolatile process data in the permanent
memory
1 Save all nonvolatile process data in the permanent memory
If the nonvolatile process data are not stored (P053.002=0),
data are lost when the electronics supply of the SIMOREG DC
Master is switched off, i.e. they have the value 0 after the
electronics supply is switched on again:
K0240: Setpoint of the motor potentiometer
K0309: Motor heating
K0310: Thyristor heating
K9195: Output of the 1st tracking/storage element
K9196: Output of the 2nd tracking/storage element
0 to 1
1
Ind: 2
FS=1
Type: O2
P052 = 3
P051 = 0
on-line
P054 OP1S – Background lighting
0 ON continuously
1 ON when panel is in use
0, 1 Ind: None
FS=0
Type: O2
P052 = 3
P051 ≥ 0
Online
P055
*
(G175)
Copy function data set
This parameter allows parameter set 1, 2, 3 or 4 to be copied
to parameter
set 1, 2, 3 or 4. This function is applicable only to parameters with 4 indices
in the function data set (see also Section 9.1, Data sets and Section 9.11,
and Section 8, Sheet G175).
0xy Do nothing
, automatic resetting value at the end of a copy
operation.
1xy The contents of parameter set x (source data set, x=1, 2, 3 or 4)
are copied
to parameter set y (target data set, y=1, 2, 3 or 4)
(parameter set x remains unchanged, the original contents of
parameter set y are overwritten).
x and y are the respective parameter set numbers (1, 2, 3 or 4)
of the source and target parameter sets.
The copy operation is started by switching P055 over into parameter mode
when P055=1xy.
During the copy operation, the numbers of the parameters being copied are
displayed on the operator panel (PMU).
At the end of the copy operation, P055 is reset to P055=0xy.
011 to 143
1
Ind: None
FS=012
Type: L2
P052 = 3
P051 = 40
Offline
r056
(G175)
Display of active function data set
1 to 4
1
Ind: None
Type: O2
P052 = 3
P057
*
(G175)
Copy Bico data set
This parameter allows parameter set 1 or 2 to be copied
to parameter set 1
or 2. This function is applicable only to parameters with 2 indices in the Bico
data set (see also Section 9.1, Data sets and Section 9.11, and Section 8,
Sheet G175).
0xy Do nothing
, automatic resetting value at the end of a copy
operation.
1xy The contents of parameter set x (source data set, x=1 or 2) are
copied
to parameter set y (target data set, y=1 or 2) (parameter
set x remains unchanged, the original contents of parameter set
y are overwritten).
x and y are the respective parameter set numbers (1 or 2) of the
source and target parameter sets.
The copy operation is started by switching P057 over into parameter mode
when P057=1xy.
During the copy operation, the numbers of the parameters being copied are
displayed on the operator panel (PMU).
At the end of the copy operation, P057 is reset to P057=0xy.
011 to 121
1
Ind: None
FS=012
Type: L2
P052 = 3
P051 = 40
Offline
r058
(G175)
Display of active Bico data set
1 to 2
1
Ind: None
Type: O2
P052 = 3
